Technical Specification
| Frequency Range: | 20 Hz to 3 MHz |
| DUT Max Temperature: | 200 ºC for 1 hour |
| Connections: | The measurement leads are connected to the analyzer (3255B/3260B) front panel BNC’s. The high current leads are connected to the high current terminals of the 3265B DC Bias Unit. 2-terminal connection to the bottom face of Device Under Test. |
| DUT size: |  |
| Safety: | When the fixture cover is opened, the safety interlock will operate and stop the DC bias current. |
| Dimensions: | 185 mm × 90 mm × 190 mm (L x W x H) |
| Weight: | 1.85 kg |
